120-230V 0.22-0.43A 50/60HZ 2800-3400rpm coververy electic o from China manufacturer

120-230V 0.22-0.43A 50/60HZ 2800-3400rpm coververy electic o

Payment Terms:	T/T,
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: PMOTOR-1

Production Capacity: 10000pieces/month

Delivery Date: 19days after placing order

Phase: Single-phase

Speed: High Speed

Usage: Household Appliance

voltage: 120-230V

current: 0.22-0.43A

rotation: 2800-3400rpm

output power: 4.8w

Means of Transport: Ocean,

Packing: standard cartons

Structure: Asynchronous Motor

Protect Feature: Explosion-proof

Function: Driving

Brand Name: jili

input power: 19.6w

frequency: 50/60HZ

torque: 23.1mN.m

certification: CCC CE C TUV ROHs

product name 120V 2800-3400RPM 0.3A 50/60HZ Cover very electric oven product descriptionmodel: pmotor-1 power
frequency: 50/60HZ

voltage: 120v-230v
frequency: 50/60HZ
certifcation: CCC,CE,CB,ROHS,TUV

product name 120V 2800-3400RPM 0.3A 50/60HZ Cover very electric oven
product descriptionmodel: pmotor-1 power
frequency: 50/60HZ
operating voltage: 120v 230v
free load speed: 2800-2400rpm at Max.ericiency speed: 2194-2690rpm
torque; 23.1-23.3mN.m

Olcu Toleransi DIN7168
Olcu	> = 0.5	> = 3	> = 6	> = 30	> = 120	> = 400	> = 1000	> = 2000
Araligi	<3	<6	<30	<120	<400	<1000	<2000	<4000
	0.1	0.1	0.2	0.3	0.5	0.8	1.2	1.2

						Max.erriciency
		(RPM)	(A)	(W)	(RPM)	(mN.m)	(A)	(A)	(W)
120V	60HZ	3400	0.34	19.7	2690	23.3	0.43	0.43	4.9
230V	50HZ	2800	0.16	19.6	2194	23.1	0.22	0.22	4.8

2800-3400RPM 120V 0.3A 50/60HZ

120-230V 0.22-0.43A 50/60HZ 2800-3400rpm coververy electic oven
